Partnummer: HF110UPS90
Medical-grade UPS battery system (IEC 60601-1) with pure sine wave output for critical patient transport and mobile care. Just 2.3 kg, up to 90 min runtime on HFNC devices, whisper-quiet and modular.
Zopec UPS90 Pure Battery System
The Zopec UPS90 Pure Battery System is a medical-grade (IEC 60601-1) portable UPS battery with pure sine wave output. At just 2.3 kg, it is purpose-built for uninterrupted power during patient transport, mobile care, and emergencies.
Key Features
- Pure Sine Wave Output: Safe for HFNC systems, patient monitors, and infusion pumps
- Line-Interactive UPS: Charges while powering devices – prevents resets during outages
- Whisper-Quiet: Solid-state cooling, no fan noise
- Modular: Link batteries in series for extended runtime
- Dual Output: AC outlet and USB ports simultaneously
- Easy Disinfection: IP22 silicone cover, hospital-wipe compatible
Runtime by Application
| Device | Runtime |
|---|---|
| HFNC (F&P Airvo2) | ~90 min |
| Heated Humidifiers | ~70 min |
| HFOV Oscillator 3100A | ~120 min |
| Tecotherm NEO | ~4 hours |
| Blood Gas Analyzers | 2-3 hours |
Included
- UPS90 Pure battery unit
- Mounting adapter
- Silicone protective cover
- Power cord
- 10 reusable zip ties
- 2 Velcro straps
- User manual
Winner of the 2023 EMS World Innovation Award.
| Model | HF110UPS90 Pure |
| Type | Line-Interactive UPS, Pure Sinusgolf |
| Gewicht | 2,3 kg (5 lbs) |
| Afmetingen | 29 x 16,5 x 5 cm |
| Voltage | 100-120V | 220-240V | 90-110V |
| Koeling | Solid-state (geen ventilator) |
| Bescherming | IP22 (siliconen hoes) |
| Display | Digitaal, alarmen bij 20%, 10%, 5% |
| Uitgangen | AC + USB |
| Modulair | Ja, koppelbaar in serie |
| Levensduur | 8 jaar |
| Garantie | 5 jaar |
- IEC 60601-1 – Medische elektrische apparatuur
- IEC 62133-2 – Draagbare lithium-ion batterijen
- UL94 V0 – Brandvertragend materiaal
